Photo #: NH 105041 Stockless Anchor (Navy Department Specifications) Figure 31 (page 158) of "The Naval Artificer's Manual", compiled and arranged by Assistant Naval Constructor (T) McCall Pate, USN, 1918. This figure shows the configuration of Stockless Anchors made according to Navy Department specifications, with a information concerning the dimensions of these anchors. See Photo # NH 105039 and Photo # NH 105042 for the text that accompanied this drawing, and Photo # NH 105040 for a chart of General Proportions of different sizes of stockless anchors. U.S. Naval Historical Center Photograph. Online Image: 177KB; 740 x 1225 pixels
