Online Library of Selected Images -- Picture Data

Photo #: NH 105036 Data on Cast-Steel Anchors, Navy Type Page 153 of "The Naval Artificer's Manual", compiled and arranged by Assistant Naval Constructor (T) McCall Pate, USN, 1918. This page provides the first page of text concerning the specifications for, and manufacture of, Navy Type Cast-Steel Anchors. See Photo # NH 105038 for the second page of text on this subject, and Photo # NH 105037 for the drawing that accompanied the text. U.S. Naval Historical Center Photograph. Online Image: 244KB; 740 x 1225 pixels

Click on the small photograph to prompt a larger view of the same image.

If you want higher resolution reproductions than this digital image, see: "How to Obtain Photographic Reproductions."

Return to Naval Historical Center home page.

Image posted 5 October 2007
