Online Library of Selected Images -- Picture Data

Photo #: NH 97217 Wreck of USS Scorpion (SSN-589) "Damaged section of the Scorpion's snorkel exhaust piping fairing. The rectangle white areas are zinc plates attached to the fairing to retard corrosion. This section is referred to as the 'turtleback' of this class submarine." Quoted from the original photo caption, which bears the date 30 January 1969. This photograph was probably taken when Scorpion was located by USNS Mizar (T-AGOR-11) in October 1968, on the Atlantic Ocean floor 10,000 feet deep, some 400 miles southwest of the Azores. Official U.S. Navy Photograph, from the collections of the Naval Historical Center. Online Image: 85KB; 740 x 585 pixels

Click on the small photograph to prompt a larger view of the same image.

If you want higher resolution reproductions than this digital image, see: "How to Obtain Photographic Reproductions."
