Photo #: NH 91891 The "Stevens Battery" Engraved plan of a section of the ship's side armor, showing armor support, backing and 10-inch iron armor, as planned for installation in 1874. This armor scheme reflects the ship's ultimate configuration, with a monitor-type armored extension around the hull at the waterline. Published in the book: "The Stevens Ironclad Battery", in 1874. The original volume is held by the Navy Department Library. U.S. Naval Historical Center Photograph. Online Image: 110KB; 650 x 675 pixels

Click on the small photograph to prompt a larger view of the same image.

If you want higher resolution reproductions than this digital image, see: "How to Obtain Photographic Reproductions."
