Online Library of Selected Images -- Picture Data

Photo #: NH 73795 USS Barnegat (AVP-10) Plate 16 of the ship's Booklet of General Plans, corrected through 18 June 1943. This is the eighth sheet of eight in this series, and includes drawings of the ship's Hull Sections at (from right) Frames 101, 112, 124, 136 & 139, with the section at Frame 145 in the upper left (all on starboard side, looking aft). The original plan has Bureau of Ships plan # 303470. U.S. Naval Historical Center Photograph. Online Image: 157KB; 1200 x 795 pixels

Click on the small photograph to prompt a larger view of the same image.

If you want higher resolution reproductions than this digital image, see: "How to Obtain Photographic Reproductions."
